ASRock ALIVEDUAL-ESATA2, GeForce M1695/nForce3 250/1000FSB/1XPCI-Ex16/3xPCI/1xAGP 8xslot/4xDUAL DDR2-800 max 8GB/integr 256MB dual VGA/HDCP/DVI-D/D-Sub/2xSATA3 RAID 0 1/2xATA133/1xeSATA/8-ch sound/G-



Preks apibūdinimas/Item:
   ASRock ALIVEDUAL-ESATA2, GeForce M1695/nForce3 250/1000FSB/1XPCI-Ex16/3xPCI/1xAGP 8xslot/4xDUAL DDR2-800 max 8GB/integr 256MB dual VGA/HDCP/DVI-D/D-Sub/2xSATA3 RAID 0 1/2xATA133/1xeSATA/8-ch sound/G-
Gamintojas/Maker: ASROCK
Modelis/Model: ALIVEDUAL-ESATA2
Gamintojo Part/No: 024772
Nuoroda/URL link: http://www.asrock.com/index.asp
Nuoroda Matrix Uab: http://www.deze.lt/products/ASROCK_ALIVEDUAL-ESATA2_024772.htm
Aprašymas PDF: http://www.deze.lt/products/
Naudojimosi instrukcija:
Svoris/Weight:
Išmatavimai/Dimensions:
Komplektacija/pakuotė:
Garantija/Warranty:
Aprašymas (ltu):
Description (eng):
  1. Support for Socket AM2+ / AM2 processors: AMD Phenom™ FX / Phenom / Athlon 64 FX / Athlon 64 X2 Dual-Core / Athlon X2 Dual-Core / Athlon 64 / Sempron processor
  2. NVIDIA® M1695 Chipset
  3. NVIDIA® nForce3 250 Chipset
  • FSB 1000 MHz (2.0 GT/s), Hyper-Transport Technology and AMD Cool 'n' Quiet Technology
  • AMD LIVE!™ Ready
  • Supports Dual Channel DDR2 1066 with AM2+ CPU, and DDR2 800/667/533 with AM2 CPU, with 4 DIMM slots, maximum capacity up to 16GB
  • ASRock AM2 Boost: ASRock Patented Technology to boost memory performance up to 12.5%
  • 1 x PCI Express x16 slot
  • 1 x AGP 8X slot
  • Untied Overclocking : During Overclocking, FSB enjoys better margin due to fixed AGP/PCIE/ PCI Buses
  • Hybrid Booster - ASRock Safe Overclocking Technology
  • Supports PCIE Gigabit LAN 10/100/1000 Mb/s
  • 2 x SATA 1.5 Gb/s connectors by NVIDIA® nForce3 250, support RAID (RAID 0, RAID 1 and JBOD) and "Hot Plug" functions
  • 2 x SATAII 3.0 Gb/s connectors by JMicron® JMB363 (PCIE x1 interface), support RAID (RAID 0, RAID 1 and JBOD), NCQ, AHCI and "Hot Plug" functions
  • 1 x eSATAII 3.0 Gb/s connector (shared with 1 SATAII port), supports NCQ, AHCI and "Hot Plug" functions
  • HDMI_SPDIF header, providing SPDIF audio output to HDMI VGA card, allows the system to connect HDMI Digital TV/projector/LCD devices.
  • 7.1 CH Windows® Vista™ Premium Level Superior Audio (C-Media CM6501 Audio Codec with UAA architecture)
  • Supports all features in Windows® Vista™ Premium
  • Supports Windows® XP Media Center Edition
  • ASRock 8CH_eSATAII I/O Plus : 1 eSATAII Port, 4 ready-to-use USB Ports


CPU - Support for Socket AM2+* / AM2 processors: AMD Phenom™ FX / Phenom / Athlon 64 FX / Athlon 64 X2 Dual-Core / Athlon X2 Dual-Core / Athlon 64 / Sempron processor
- AMD LIVE!™ Ready
- Supports AMD's Cool 'n' Quiet Technology
- FSB 1000 MHz (2.0 GT/s)
- Supports Untied Overclocking Technology
- Supports Hyper-Transport Technology

*If you use AM2+ CPU on AM2 chipset motherboard, the system bus speed will downgrade from HT3.0 (5200 MT/s) to HT1.0 (2000 MT/s), but the CPU frequency will not be influenced.

*If you adopt AMD Phenom™ X4 AM2+ CPU on this motherboard with AGP VGA cards, please click here for AGP VGA Card support list.
Chipset - Northbridge: NVIDIA® M1695
- Southbridge: NVIDIA® nForce3 250
Memory - Dual Channel DDR2 memory technology
- 4 x DDR2 DIMM slots
- Supports DDR2 1066*/800/667/533 non-ECC, un-buffered memory
- Max. capacity of system memory: 16GB**

*Support with AM2+ CPU.

**Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows® XP and Windows® Vista™. For Windows® XP 64-bit and Windows® Vista™ 64-bit with 64-bit CPU, there is no such limitation.
BIOS - 4Mb AMI BIOS
- AMI Legal BIOS
- Supports "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- Supports Jumperfree
- SMBIOS 2.3.1 Support
 Audio, Video and Networking
Graphics - n/a
Audio - 7.1 CH Windows® Vista™ Premium Level Superior Audio (C-Media CM6501 Audio Codec with UAA architecture)
LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s
- Realtek RTL8111B/RTL8111C
- Supports Wake-On-LAN
 Expansion / Connectivity
Slots - 1 x PCI Express x16 slot
- 3 x PCI slots
- 1 x AGP 8X slot*

*If you plan to install Windows® Vista™ 32-bit / Vista™ 64-bit OS on this motherboard, please click here to read instructions and limitation carefully. For Windows® 2000 / XP / XP 64-bit OS, there is no such limitation.
Connector - 2 x SATA 1.5 Gb/s connectors by NVIDIA® nForce3 250, support RAID* (RAID 0, RAID 1 and JBOD) and "Hot Plug" functions
- 2 x SATAII 3.0 Gb/s connectors by JMicron® JMB363 (PCIE x1 interface), support RAID (RAID 0, RAID 1 and JBOD), NCQ, AHCI and "Hot Plug" functions
- 1 x eSATAII 3.0 Gb/s connector (shared with 1 SATAII port), supports NCQ, AHCI and "Hot Plug" functions
- 2 x ATA133 IDE connectors (support 4 x IDE devices)
- 1 x Floppy connector
- 1 x IR header
- 1 x HDMI_SPDIF header
- CPU/Chassis FAN connector
- 24 pin ATX power connector
- 4 pin 12V power connector
- CD in header
- Front panel audio connector
- 1 x USB 2.0 header (supports 2 USB 2.0 ports)
- 1 x WiFi header

*RAID function is only available under Windows® 2000, XP or XP 64-bit OS.
Rear Panel I/O ASRock 8CH_eSATAII I/O Plus
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x Serial Port: COM1
- 1 x Parallel Port (ECP/EPP Support)
- 4 x Ready-to-Use USB 2.0 Ports
- 1 x eSATAII Port
- 1 x RJ-45 Port
- Audio Jack: Side Speaker / Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone
 Other Features / Miscellaneous
Hybrid Booster - CPU Frequency Stepless Control
- ASRock U-COP
- Boot Failure Guard (B.F.G.)
- ASRock AM2 Boost: ASRock Patented Technology to boost memory performance up to 12.5%
Support CD - Drivers, Utilities, AntiVirus Software (Trial Version)
Accessories - Quick Installation Guide, Support CD, I/O Shield
- Floppy/ATA 133 Cables
- 2 x SATA Data Cables (optional)
- 1 x SATA 1 to 1 Power Cable (optional)
- 1 x HDMI_SPDIF Cable (optional)
Hardware Monitor - CPU Temperature Sensing
- Chassis Temperature Sensing
- CPU Fan Tachometer
- Chassis Fan Tachometer
- CPU Quiet Fan
- Voltage Monitoring: +12V, +5V, +3.3V, Vcore
Form Factor - ATX Form Factor: 12.0-in x 8.4-in, 30.5 cm x 21.3 cm
OS - Microsoft® Windows® 2000 / XP / XP Media Center / XP 64-bit / Vista™ / Vista™ 64-bit compliant
Certifications - FCC, CE, WHQL
Opisanije (ru):
Informacje o produkcie (pol):
Galimi priedai (optional accesories, supplies):
Aptarti forume:
Brūkšninis kodas (EAN code):

Gamintojas pasilieka teisę keisti specifikacijas, be išankstinio įspėjimo.
Product specification is subject to change without prior notice.
