CPU

AMD Socket AM2+ / AM2 Processors
AMD Phenom™ / Athlon64 FX / Athlon64 X2/Athlon64 / Sempron processors
AMD Cool 'n' Quiet™ Technology
AMD64 architecture enables simultaneous 32-bit and 64-bit computing
AMD Live!™ Ready
*Support CPU up to 95W

Chipset

AMD 780G/SB700

System Bus

2000/1600 MT/s for AM2 CPU
Up to 5200 MT/s; HyperTransport™ 3.0 interface for AM2+ CPU

Memory

4 x240-pin DIMM, Max. 8 GB, DDR2 1066/800/667/533 ECC,Non-ECC,Un-buffered Memory
Dual Channel memory architecture
*DDR2 1066 is supported by AM2+ CPU only
**Refer to www.asus.com or user manual for Memory QVL (Qualify Vendor List)
***When installing total memory of 4GB capacity or more, Windows® 32-bit operation system may only recognize less than 3GB. Hence, a total installed memory of less than 3GB is recommended.

Expansion Slots

1 x PCIe x16
1 x PCIe x1
2 x PCI

VGA

Integrated ATI RV610-based Direct x10.1 graphics
Maximum shared memory of 256 MB
Supports HDMI™ Technology with HDCP compliant with max. resolution 1920 x 1080p
Supports DVI-D with max. resolution 2560x1600 (@ 60Hz dual-link)
Supports RGB with max. resolution 2048 x 1536 (@85Hz)
Dual VGA output support:
RGB & DVI/HDMI
Hybrid CrossFireX Support

*To playback the HD-DVD and Blu ray Disc we recommended system configuration above Graphic shared memory 256MB/Dual-Core CPU minimum/Minimum 1GB memory of Dual-channel DDR2 667 or Single-chanel DDR2 800.
**Due to AMD Hybrid CFX driver is under verifying, we will offer you the latest beta driver on our website. Please download the latest driver and enjoy this function for greater graphics performance.

Storage

Southbridge
1 xUltraDMA 133/100
6 xSATA 3 Gb/s ports
Support RAID 0,1,10

LAN

PCIe Gigabit LAN

Audio

ALC883 High Definition Audio 8 -Channel CODEC

USB

12 USB 2.0 ports (8 ports at mid-board, 4 ports at back panel)

Overclocking Features

SFS (Stepless Frequency Selection)
- FSB tuning from 200MHz to 300MHz at 1MHz increment
- Adjustable CPU Voltage at 0.025V increment
Overclocking Protection
- ASUS C.P.R.(CPU Parameter Recall)

Special Features

ASUS MyLogo 2
ASUS EZ Flash 2
ASUS CrashFree BIOS 3
ASUS Q-Fan

Back Panel I/O Ports

1 x DVI
1 x VGA
1 x PS/2 Keyboard
1 x PS/2 Mouse
1 x LAN(RJ45) port
4 x USB 2.0/1.1
8 -Channel Audio I/O
1 x HDMI

Internal I/O Connectors

4 x USB connectors supports additional 8 USB 2.0 ports
1 x Floppy disk drive connector
1 x IDE connector
6 x SATA connectors
1 x CPU Fan connector
1 x Chassis Fan connector
1 x S/PDIF Out connector
1 x4-pin ATX 12V Power connector
1 x HDJ1 connectors
Front panel audio connector
COM connector
System Panel
CD audio in
24-pin EATX power connector

BIOS

8 Mb Flash ROM
DMI 2.0
AMI BIOS
PnP
WfM 2.0
SM BIOS 2.4

Accessories

User's manual
2x Serial ATA cables
1x2 port SATA power cables(includes one 2 in 1 power cable)
1 x UltraDMA 133/100/66 cable
1 x FDD cable
1 x I/O Shield

Support Disc

Drivers
ASUS PC Probe II
Anti-virus software (OEM version)
ASUS LiveUpdate Utility

Form Factor

uATX Form Factor
9.6 inch x 9.0 inch ( 24.4 cm x 22.9 cm )
