MSI X58 Platinum Intel Core i7/ X58 +ICH10R/ 6.4GT/1333 FSB/ 2xPCI-Ex16/2xPCI/3xPCI-E/ 7,1ch 3x DDR3 DIMM/ 8xSATAII/eSATAx1/ ATA/RAID/Gbe LAN/ SLI/ TPM/ ATX { X58 PLATINUM }



Preks apibūdinimas/Item:
   MSI X58 Platinum Intel Core i7/ X58 +ICH10R/ 6.4GT/1333 FSB/ 2xPCI-Ex16/2xPCI/3xPCI-E/ 7,1ch 3x DDR3 DIMM/ 8xSATAII/eSATAx1/ ATA/RAID/Gbe LAN/ SLI/ TPM/ ATX { X58 PLATINUM }
Gamintojas/Maker: MSI (MICROSTAR)
Modelis/Model: X58-Platinum-Intel-Core-i7
Gamintojo Part/No: 032918
Nuoroda/URL link: http://global.msi.com.tw/index.php
Nuoroda Matrix Uab: http://www.deze.lt/products/MSI_X58-Platinum-Intel-Core-i7_032918.htm
Aprašymas PDF: http://www.deze.lt/products/
Naudojimosi instrukcija:
Svoris/Weight:
Išmatavimai/Dimensions:
Komplektacija/pakuotė:
Garantija/Warranty:
Aprašymas (ltu):
Description (eng): Processor:
Supports Intel® i7 based processors in LGA1366 package.

Northbridge:
Intel® X58 Chipset
- Supports QPI up to 6.4GT/s

Southbridge:
Intel® ICH10R Chipset
- Hi-Speed USB (USB2.0) controller, 480Mb/sec, up to 12 ports.
- 6 SATAII ports with transfer rate up to 3Gb/s.
- PCI Master v2.3, I/O APIC.
- ACPI 2.0 compliant.
- Serial ATA RAID 0/1/5/10.
- Integrated AHCI controller.

Main Memory:
Supports six unbuffered DIMM of 1.5 Volt DDR3 800/1066/1333 SDRAM, 24GB Max
- Supports 1Gb/ 2Gb/ 4Gb DRAM size
- Supports x8 / x16 data lines per DIMM
- Supports up to 3 channel mode

PCI Slots:
2 PCI Express gen2 x16 slots
- supports ATI® Crossfire™
3 PCI Express gen2 x1 slots
2 PCI slot, support 3.3V/ 5V PCI bus Interface

On-Board IDE/SATA:
One Ultra DMA 66/100/133 IDE controller integrated in JMicron® 363.
- Supports PIO, Bus Master operation modes.
- Can connect up to two Ultra ATA drives.
SATAII controller integrated in ICH10R/JMicron® 322 / 362 chipest
- Up to 3Gb/s transfer speed.
- Supports six SATAII ports by ICH10R
- Supports two SATAII ports by JMicron 322, support SATA RAID 0/1/JBOD.
- Supports one eSATA port by JMicron 363.
- Supports AHCI controller with SATA RAID 0/1/5/10 by ICH10R.

Audio:
Chipset integrated by Realtek® ALC888
- Flexible 8-channel audio with jack sensing
- Compliant with Azalia 1.0 Spec
- Meet Microsoft Vista Premium spce

LAN:
Supports two PCI Express LAN 10/100/1000 Fast Ethernet by Realtek 8111C.

IEEE1394 / FireWire:
JMicron® 381 chipset
- Supports up to two 1394 ports. (Rear panel x1, pinheader x1)
- Transfer rate is up to 400Mbps.

Internal I/O Connectors:
ATX 24-Pin power connector
8-pin ATX 12V power connector
CPU / System x 5 FAN connectors
CD-in connector
Front panel audio connector
Front panel connector
1 x chasis intrusion connector
1 x serial port pinheader
2 x USB 2.0 connectors
8 x Serial ATAII connectors
1 x ATA133 connector
1 x IEEE1394 connector support additional 1 port
1 x GreenPower Genie connector
1 x Reset Button
1 x Power Button
1 x SPDIF-out connector
1 x D-LED2 connector
1 x TPM module connector

Back Panel I/O Ports:
1 x Clear CMOS button
1 x PS/2 Keyboard
1 x PS/2 Mouse
1 x eSATA port
1 x IEEE1394 port
8 x USB 2.0 ports
2 x RJ45 LAN Jacks
1 x 6 in 1 audio jack
1 x Optical SPDIF-out

BIOS:
The mainboard BIOS provides "Plug & Play" BIOS which detects the peripheral devices and expansion cards of the board automatically.
The mainboard provides a Desktop Management Interface(DMI) function which records your mainboard specifications.

Form Factor:
30.5cm(L) x 24.4cm(W) ATX Form Factor
9 mounting holes.

Opisanije (ru):
Informacje o produkcie (pol):
Galimi priedai (optional accesories, supplies):
Aptarti forume:
Brūkšninis kodas (EAN code):

Gamintojas pasilieka teisę keisti specifikacijas, be išankstinio įspėjimo.
Product specification is subject to change without prior notice.
