Asus COMMANDO, iP965/ICH8R/1066FSB/4x DUAL DDR2-800/2x PCI-Ex16/4x PCI 2.2/2xATA/6xSATA2 RAID 0 1 5 10/8ch audio supremeFX/Dual G-LAN/10xUSB/2xIEEE1394a/SPDIF/ATX



Preks apibūdinimas/Item:
 Asus COMMANDO, iP965/ICH8R/1066FSB/4x DUAL DDR2-800/2x PCI-Ex16/4x PCI 2.2/2xATA/6xSATA2 RAID 0 1 5 10/8ch audio supremeFX/Dual G-LAN/10xUSB/2xIEEE1394a/SPDIF/ATX
Gamintojas/Maker: ASUS
Modelis/Model: COMMANDO
Gamintojo Part/No: 014336
Nuoroda/URL link: http://www.asus.com/products.aspx
Nuoroda Matrix Uab: http://www.deze.lt/products/ASUS_COMMANDO_014336.htm
Aprašymas PDF: http://www.deze.lt/products/
Naudojimosi instrukcija:
Svoris/Weight:
Išmatavimai/Dimensions:
Komplektacija/pakuotė:
Garantija/Warranty:
Aprašymas (ltu):
Description (eng): -Support Intel® next generation 45nm Multi-core CPU
-Intel® Quad-core CPU Ready
-Intel® Core™2 Extreme / Core™2 Duo Ready
-Intel P965 chipsets
-Dual-channel DDR2 800/667/533
-Extreme Tweaker
-SupremeFX / DTS Connect / Noise Filter
-LCD Poster
-Onboard Switches

CPU
Intel Socket 775 Core™2 Extreme/Core™2 Duo/Pentium® Extreme/Pentium® D/Pentium® 4/Celeron Processors
Compatible with Intel® 05B/05A/06 processors
Support Intel® next generation 45nm CPU
* Refer to www.asus.com for Intel CPU support list
** Please update the latest BIOS to support Intel 45nm CPU
Chipset
Intel P965
ICH8R
Intel Fast Memory Access Technology
Front Side Bus
1066/800/533 MHz
Memory
4 x DIMM, Max. 8 GB, DDR2 800/667/533 Non-ECC,Un-buffered Memory
Dual Channel memory architecture
* Refer to www.asus.com or user manual for Memory QVL (Qualify Vendor List)
Expansion Slots
2 x PCIe x16 (@ x16 and x4 mode)
4 x PCI 2.2
Storage
Southbridge
6 xSATA 3 Gb/s ports Support RAID 0,1,5,10 PATA controller
LAN
Dual Gigabit LAN controllers, both featuring AI NET2;Marvell® PCI-E and PCI Gigabit LAN controllers
Marvell® PCI-E and PCI Gigabit LAN controllers
Audio
SupremeFXfeaturing ADI® 1988B Codec Audio Card
Coaxial / Optical S/PDIF out ports
ASUS Noise Filter
Support Jack-Sensing, Enumeration, Multi-streaming and Jack-Retasking
DTS® Connect
IEEE 1394
2 x 1394a ports (one at midboard; one at back panel)
USB
10 USB 2.0 ports (6 ports at mid-board, 4 ports at back panel)
Overclocking Features
Extreme Tweaker
Intelligent overclocking tools
- AI Overclocking (intelligent CPU frequency tuner)
- ASUS AI Booster Utility
- ASUS AI NOS (Non-delay Overclocking System)
- ASUS O.C. Profile: overclocking configuration-sharing tool Overclocking Protection- ASUS C.P.R.(CPU Parameter Recall)
Special Features
ASUS MyLogo 3
ASUS EZ Flash 2
ASUS CrashFree BIOS 3
Q-Connector
LCD Poster
Onboard Switches: Power / Reset / Clr CMOS
Back Panel I/O Ports
1 x PS/2 Keyboard
1 x PS/2 Mouse
1 x S/PDIF Out
1 x IEEE 1394a
2 x LAN(RJ45) port
4 x USB 2.0/1.1
Internal I/O Connectors
3 x USB connectors support additional 6 USB ports
1 x Floppy disk drive connector
1 x IDE connector
6 x SATA connectors
1 x IEEE 1394a connector
1 x CPU Fan connector
6 x Chassis Fan connector
1 x Power Fan connector
1 x Azalia Digital Header
1 x8-pin ATX 12V Power connector
24 -pin ATX Power connector
3 x thermal sensor connector
Chassis Intrusion connector
System Panel Connector
BIOS
8 Mb Flash ROM
DMI 2.0

AMI BIOS
PnP
WfM 2.0
SM BIOS 2.3
ACPI 2.0a
Multi-language BIOS
ASUS EZ Flash 2
ASUS CrashFree BIOS3
Manageability
WfM 2.0,DMI 2.0,WOL by PME,PXE
Accessories
User's manual
Cable Ties
IEEE1394a module
x UltraDMA 133/100/66 cable
x Floppy disk drive cable
x SATA cable
SATA power cable
I/O Shield
3 in 1 Q-connector
IEEE 1394 port module
Optional Fanfor Water-Cooling or Passive-Cooling only
Support Disc
Drivers
ASUS PC Probe II
ASUS Update
ASUS AI Booster
Futuremark® 3DMark06 Advanced Edition
Kaspersky Anti-Virus software (full version)
Form Factor
ATX Form Factor
12 inch x 9.6 inch ( 30.5 cm x 24.5 cm )
Opisanije (ru):
Informacje o produkcie (pol):
Galimi priedai (optional accesories, supplies):
Aptarti forume:
Brūkšninis kodas (EAN code):

Gamintojas pasilieka teisę keisti specifikacijas, be išankstinio įspėjimo.
Product specification is subject to change without prior notice.
