CPU

AMD Socket AM2+ / AM2 Processors
for Athlon64 / Athlon64 FX / Athlon64 X2 / Sempron / AM2+
AMD Cool 'n' Quiet™ Technology
AMD64 architecture enables simultaneous 32-bit and 64-bit computing

Chipset

NVIDIA GeForce 7050PV/nForce 630a

System Bus

2000/1600 MT/s

Memory

4 x 240-pin DIMM, Max. 8 GB, DDR2 1066/800/667/533 ECC,Non-ECC,Un-buffered Memory
Dual Channel memory architecture
*DDR2 1066 is supported by AM2+ CPU only

Expansion Slots

1 x PCIe x16
1 x PCIe x1
2 x PCI

VGA

Integrated Nvidia® Geforce®7Series Shader model3.0 DirectX 9 graphics processor
Max. shared memory: 256 MB
Supports RGB with max. resolution 1920 x1440 (@70Mhz*32bpp/75Mhz*16bpp)
Supports DVI-D with max. resolution 1920 x1200 (@60Mhz)
*Due to the chipset limitation, only MPEG 2 & WMV Offload can support HD format 1920 x 1080p.
*When playing HD DVD and Blu-ray disc the suggested system configuration above: DDR2 800 1GB*2 /Althon 64 X2 4400+/Graphic shared memory 256MB/Purevideo HD support.

Storage

1 xUltraDMA 133/100
4 xSATA 3 Gb/s ports ATAPI support ,AHCI mode

LAN

Phy Gigabit LAN

Audio

VT1708 High Definition Audio 8 -Channel CODEC
Supports Anti Pop Funtion and Vista Premium
Supports S/PDIF out interface, Jack-detect and multi-streaming

USB

12 USB 2.0 ports (6 on back I/O, 6 on board)

ASUS Unique Features

ASUS Express Gate:
1. Access the Internet in 5-second* boot time without entering Windows
2. A built-in OS offers instant fun platform for Internet and Instant Messenger!
3. Friendly Picture Manager Interface
* The actual boot time is subject to hardware configurations and product models.
ASUS Quiet Thermal Solution:
- ASUS Q-Fan
ASUS EZ DIY:
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 2
Other: ASUS MyLogo 2

Back Panel I/O Ports

1 x DVI
1 x VGA
1 x PS/2 Keyboard
1 x LAN(RJ45) port
6 x USB 2.0/1.1
8 -Channel Audio I/O

Internal I/O Connectors

3 x USB connectors supports additional 6 USB 2.0 ports
High Definition Front panel audio connector
1 x CD audio-in connector
1 x S/PDIF output connector
1 x Floppy disk drive connector
1 x IDE connector for two devices
1 x LPT connector
CPU / Chassis/PWR Fan connectors
Chassis Intrusion connector
24-pin EATX power connector
4-pin ATX 12V Power connector
1 x System Panel connector

BIOS

8 Mb Flash ROM
AMI BIOS, PnP, DMI2.0, WfM2.0, SMBIOS 2.4

Manageability

WfM 2.0, DMI 2.0, WOR by Ring, PME Wake Up,WO_USB,WO_KB/MS

O/S Compatibility

Windows Vista
Windows XP
Windows 2000

Accessories

User' s manual
1 x Serial ATA cable
1 x SATA power cable
1 x UltraDMA 133/100 cable
1 x I/O Shield
* Note: The floppy disk drive cable is purchased separately

Support Disc

Drivers
ASUS PC Probe II
ASUS LiveUpdate Utility
Anti -virus software(OEM version)

Form Factor

uATX Form Factor
9.6" x 9" ( 24.4 cm x 22.86 cm )
