GIGABYTE MA74GM-S2H AM2+ 790FX+SB600 / 4000 FSB/ 2xPCI-E x16/ 2xPCI/PCI-Ex1/ PCIDual 4xDDRII 1066/800/667/8-ch audio/ VIDEO/ 8xSATAII / 1xPATA/ 2xGb/Raid 0,1,0+1/G- LAN/mATX



Preks apibūdinimas/Item:
 GIGABYTE MA74GM-S2H AM2+ 790FX+SB600 / 4000 FSB/ 2xPCI-E x16/ 2xPCI/PCI-Ex1/ PCIDual 4xDDRII 1066/800/667/8-ch audio/ VIDEO/ 8xSATAII / 1xPATA/ 2xGb/Raid 0,1,0+1/G- LAN/mATX
Gamintojas/Maker: GIGABYTE
Modelis/Model: MA74GM-S2H
Gamintojo Part/No: 024222
Nuoroda/URL link: http://www.gigabyte.com.tw/
Nuoroda Matrix Uab: http://www.deze.lt/products/GIGABYTE_MA74GM-S2H_024222.htm
Aprašymas PDF: http://www.deze.lt/products/
Naudojimosi instrukcija:
Svoris/Weight:
Išmatavimai/Dimensions:
Komplektacija/pakuotė:
Garantija/Warranty:
Aprašymas (ltu):
Description (eng):
  1. Supports AMD Athlon/ Sempron processors*
  2. Solid capacitors design in CPU VRM
  3. Dual Channel DDR2 800 for outstanding system performance
  4. Integrated ATI Radeon 2100-based graphics
  5. Ultimate graphics performance with PCI-Ex16 interface
  6. Integrated SATA 3Gb/s with RAID function
  7. Features high speed Gigabit Ethernet connection
  8. Integrated 6/8-Channel** High Definition audio
  9. Integrated HDMI/ DVI interface with HDCP


CPU
  1. Support for Socket AM2+/ AM2 processors: AMD Phenom™FX processor/ AMD Phenom™ processor/ AMD Athlon™ 64 FX processor/AMD Athlon™ 64 X2 Dual-Core processor/AMD Athlon™ 64 processor/AMD Sempron™ processor
(Note) If you install AMD AM2+ CPU on AM2 motherbord, the system bus speed will downgrade from HT3.0(5200MHz) to HT1.0(2000 MT/s) spec; however, the frequency of AM2+ CPU will not be impacted. Please refer "CPU Support List" for more information.
Hyper Transport Bus
  1. 2000 MT/s
Chipset
  1. North Bridge: AMD 740G
  2. South Bridge: AMD SB700
Memory
  1. 2 x 1.8V DDR2 DIMM sockets supporting up to 8 GB of system memory (Note 1)
  2. Dual channel memory architecture
  3. Support for DDR2 800/667 MHz memory modules
Onboard Graphics
  1. Integrated in the North Bridge
Audio
  1. Realtek ALC888 codec
  2. High Definition Audio
  3. 2/4/5.1/7.1-channel (Note 2)
  4. Support for S/PDIF Out
  5. Support for CD In
LAN
  1. Realtek 8111C chip (10/100/1000 Mbit)
Expansion Slots
  1. 1 x PCI Express x16 slot
  2. 1 x PCI Express x1 slot
  3. 2 x PCI slots
Storage Interface South Bridge:
  1. 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
  2. 6 x SATA 3Gb/s connectors supporting up to 6 SATA 3Gb/s devices
  3. Support for SATA RAID 0, RAID 1 and RAID 10
iTE IT8718 chip:
  1. 1 x floppy disk drive connector supporting up to 1 floppy disk drive
USB Integrated in the South Bridge
  1. Up to 12 USB 2.0/1.1 ports (4 on the back panel, 8 via the USB brackets connected to the internal USB headers)
Internal I/O Connectors
  1. 1 x 24-pin ATX main power connector
  2. 1 x 4-pin ATX 12V power connector
  3. 1 x floppy disk drive connector
  4. 1 x IDE connector
  5. 6 x SATA 3Gb/s connectors
  6. 1 x CPU fan header
  7. 1 x system fan header
  8. 1 x front panel header
  9. 1 x front panel audio header
  10. 1 x CD In connector
  11. 1 x S/PDIF Out header
  12. 4 x USB 2.0/1.1 headers
  13. 1 x Serial port header
  14. 1 x Trusted Platform Module (TPM) header
  15. 1 x chassis intrusion header
  16. 1 x power LED header
Back Panel Connectors
  1. 1 x PS/2 keyboard port
  2. 1 x Parallel port
  3. 1 x D-Sub port
  4. 1 x DVI-D port (Note 3)
  5. 1 x HDMI port
  6. 1 x coaxial S/PDIF Out connector
  7. 4 x USB 2.0/1.1 ports
  8. 1 x RJ-45 port
  9. 3 x audio jacks (Line In/Line Out/Microphone)
I/O Controller
  1. ITE IT8718 chip
H/W Monitoring System voltage detection
  1. CPU/System temperature detection
  2. CPU/System fan speed detection
  3. CPU overheating warning
  4. CPU/System fan fail warning
  5. CPU/System fan speed control (Note 4)
BIOS
  1. 1 x 8 Mbit flash
  2. Use of licensed AWARD BIOS
  3. PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Unique Features
  1. Support for @BIOS
  2. Support for Download Center
  3. Support for Q-Flash
  4. Support for EasyTune (Note 5)
  5. Support for Xpress Install
  6. Support for Xpress Recovery2
  7. Support for Virtual Dual BIOS
Bundle Software
  1. Norton Internet Security (OEM version)
Operating System
  1. Support for Microsoft Windows Vista/ XP
Form Factor
  1. Micro ATX Form Factor; 24.4cm x 23.4cm
Opisanije (ru):
Informacje o produkcie (pol):
Galimi priedai (optional accesories, supplies):
Aptarti forume:
Brūkšninis kodas (EAN code):

Gamintojas pasilieka teisę keisti specifikacijas, be išankstinio įspėjimo.
Product specification is subject to change without prior notice.
